Series 320 EURO 7.6 standard Type Pneumatic Quick Couplings

Flow Capacity:2100 L/Min
Nominal flow dia:7.6 mm
Material:
Socket：Nickel-plated brass/steel
Plug:Hardened zinc-plated steel
Temperature range(NBR)：-20°C to +100°C
Max.working pressure：35Bar
Standard and Change:
7.6 EURO7.6
Rectus 25ka、26ka,Legris series 25\26
Tema 1600, Auto FLO 24,Bosch size 3
Parker RF-1/4,PE/PEF52,Cejn 320，
Feature:
One-hand operated
Unbaffled design poppet
Low connection force
Optional double shut-off
