KIS-PP Series Push And Pull Type Quick Couplings

KIS-PP Series Push And Pull Type Quick Couplings

Materials
Coupling:Steel(zinc chromate plating)
Nipple: Hardend steel (zinc chromate plating)
Product feature
1. Meets the requirements of ISO7241-1-Series A.
2.Double acting sleeve(Push-pull) Can push-connecting or pull-disconnection.
3. Modular construction, broad choice of end, meets international standard,
for example ISO,DN.SAE,BS.
4.Critical parts are induction hardened for durability.
5.Couplers and nipple are precision.

Availability:



Inquire Add to Basket

Product Description

Interchange

Parker 2000 Faster CPV-CNV,Hydac HP Series

Ordering code

KIS-2 PP

Specifications

Body size	2	3	4	6	8
Rated pressure(MPa)	34.5	27.6	27.6	17.3	13.8
Rated flow(L/Min)	11	22	45	105	185
Temperture range(std seals)	-20℃~+80℃

Dimensions

KIS-PP Series Push And Pull Type Quick Couplings

PART NO.	ISO	Thread	L	L1	L2	L3	D1	D2	Ch1	Ch2
KIS-2PP-G02SP	6.3	G1/4	89.5	64	44	18.5	26	12	19	19
KIS-3PP-G03SP	10	G3/8	95	67	51	22.8	32	17.3	22	22
KIS-4PP-G04SP	12.5	G1/2	99.3	71	61	32.7	38	20.5	27	27
KIS-6PP-G06SP	20	G3/4	126.5	92	65	30.5	46	29	36	36
KIS-8PP-G08SP	25	G1	139	104	72	72	50	34.3	41	41

KIS-PP Series Push And Pull Type Quick Couplings1

Type			Body
Thread	O.D.	L4	2	3	4	6	8
M14X1.5	L8	10	√	√	√
M16X1.5	L10	11		√	√
M18X1.5	S10	12		√	√	√
M20X1.5	S12	12				√
M22X1.5	S14	14			√	√
M24X1.5	S16	14			√	√
M26X1.5	L18	12				√	√
M30X2	S20	16				√	√
M36X2	S25	18					√
M42X2	S30	20					√

KIS-PP Series Push And Pull Type Quick Couplings2

Type			Body
Thread	O.D.	L4	2	3	4	6	8
M14X1.5	L8	26	√	√	√
M16X1.5	L10	26		√	√
M18X1.5	S10	27		√	√	√
M20X1.5	S12	27		√	√	√
M22X1.5	S14	27			√	√
M24X1.5	S16	29			√	√
M26X1.5	L18	34				√	√
M30X2	S20	36				√	√
M36X2	S25	49					√
